| Modellnummer: | ZR48KC-TFD-522 |
| MOQ: | 1 |
| Lieferzeit: | 1-7 Tage |
| Zahlungsbedingungen: | T/T |
Dieser generalüberholte Scroll-Kompressor ist für Kühlanwendungen im mittleren Temperaturbereich konzipiert und verfügt über die fortschrittliche Scroll Digital®-Technologie für eine effiziente, stufenlose Leistungsmodulation.
| Modell Nr. | Kühlleistung (Bewertungspunkt 7,2) | Nenn-PS | Hubraum cm³/U | Nennstrom FLA | Gewicht (kg) |
|---|---|---|---|---|---|
| ZR22K3PFJ522 | 5240 | 1,83 | 30.7 | 9.6 | 26 |
| ZR28K3PFJ522 | 6970 | 2.33 | 39.2 | 12.9 | 27.3 |
| ZR28K3EPFJ522 | 6970 | 2.33 | 39.2 | 12.9 | 27.3 |
| ZR34K3PFJ522 | 8260 | 2,83 | 46.1 | 13.6 | 29.5 |
| ZR34K3EPFJ522 | 8260 | 2,83 | 46.1 | 13.6 | 29.5 |
| ZR36K3PFJ522 | 8850 | 3 | 49,5 | 16.4 | 29.5 |
| ZR40K3PFJ522 | 9620 | 3.33 | 54.19 | 17.1 | 32 |
| ZR42K3PFJ522 | 10140 | 3.5 | 56,8 | 17.1 | 30 |
| ZR47K3PFJ522 | 11500 | 3.9 | 64.1 | 19.3 | 32.6 |
| ZR68KCPFJ522 | 16800 | 5,75 | 93 | 28.2 | 43,5 |
| ZR28K3TFD522 | 6970 | 2.33 | 39.2 | 5 | 26 |
| ZR28K3ETFD522 | 6970 | 2.33 | 39.2 | 5 | 26 |
| ZR36K3TFD522 | 8850 | 3 | 49,5 | 5.7 | 29.5 |
| ZR40K3TFD522 | 9260 | 3.33 | 51.2 | 6.4 | 32 |
| ZR47KCTFD522 | 11400 | 3.9 | 63.2 | 7.2 | 32.6 |
| ZR47KCETFD522 | 11400 | 3.9 | 63.2 | 7.2 | 32.6 |
| ZR48KCTFD522 | 11500 | 4.1 | 67.2 | 7.5 | 38 |
| ZR48KCETFD522 | 11500 | 4.1 | 67.2 | 7.5 | 38 |
| ZR54KCTFD522 | 13000 | 4.5 | 73,2 | 8.2 | 35,5 |
| ZR57KCTFD522 | 13660 | 4,75 | 76,9 | 8.2 | 36 |
| ZR57KCETFD522 | 13660 | 4,75 | 76 | 8.2 | 36 |
| ZR61KCTFD522 | 14700 | 5 | 82,4 | 10 | 35.9 |
| ZR61KCETFD522 | 14700 | 5 | 82,4 | 10 | 35.9 |
| ZR68KCTFD522 | 16500 | 5,75 | 93 | 10 | 38.2 |
| ZR72KCTFD522 | 17800 | 6 | 98 | 10 | 38.2 |
| ZR72KCETFD522 | 17800 | 6 | 98 | 10 | 38.2 |
| ZR81KCTFD522 | 19800 | 6,75 | 110.6 | 12 | 40 |
| ZR81KCETFD522 | 19800 | 6,75 | 110.6 | 12 | 40 |
| ZR94KCTFD522 | 23000 | 8 | 127.2 | 16.2 | 59 |
| ZR94KCTFD523 | 23200 | 8 | 127.2 | 16.2 | 58.2 |
| ZR94KCETFD523 | 23200 | 8 | 127.2 | 16.2 | 58.2 |
| ZR108KCTFD522 | 26670 | 9 | 147,5 | 17.3 | 64 |
| ZR108KCETFD523 | 26670 | 9 | 147,5 | 17.3 | 64 |
| ZR108KCTFD523 | 26900 | 9 | 144,5 | 17.3 | 62,7 |
| ZR125KCTFD522 | 30660 | 10 | 171,4 | 19.2 | 64 |
| ZR125KCETFD523 | 31000 | 10 | 165,6 | 19.2 | 62,7 |
| ZR125KCTFD523 | 31000 | 10 | 165,6 | 19.2 | 62,7 |
| ZR144KCTFD522 | 34700 | 12 | 191,7 | 19.6 | 62,7 |
| ZR144KCETFD523 | 34700 | 12 | 191,7 | 19.6 | 62,7 |
| ZR144KCTFD523 | 34700 | 12 | 191,7 | 19.6 | 62,7 |
| ZR16M3TWD551 | 37700 | 13 | 204.3 | 25 | 103.1 |
| ZR16M3ETWD551 | 37700 | 13 | 204.3 | 17.3 | 103 |
| ZR19M3TWD551 | 45900 | 15 | 241,9 | 23.8 | 112.1 |
| ZR19M3ETWD551 | 45900 | 15 | 241,9 | 23.8 | 119 |
|
|
| Modellnummer: | ZR48KC-TFD-522 |
| MOQ: | 1 |
| Verpackungsdetails: | Hölzernes Verpacken |
| Zahlungsbedingungen: | T/T |
Dieser generalüberholte Scroll-Kompressor ist für Kühlanwendungen im mittleren Temperaturbereich konzipiert und verfügt über die fortschrittliche Scroll Digital®-Technologie für eine effiziente, stufenlose Leistungsmodulation.
| Modell Nr. | Kühlleistung (Bewertungspunkt 7,2) | Nenn-PS | Hubraum cm³/U | Nennstrom FLA | Gewicht (kg) |
|---|---|---|---|---|---|
| ZR22K3PFJ522 | 5240 | 1,83 | 30.7 | 9.6 | 26 |
| ZR28K3PFJ522 | 6970 | 2.33 | 39.2 | 12.9 | 27.3 |
| ZR28K3EPFJ522 | 6970 | 2.33 | 39.2 | 12.9 | 27.3 |
| ZR34K3PFJ522 | 8260 | 2,83 | 46.1 | 13.6 | 29.5 |
| ZR34K3EPFJ522 | 8260 | 2,83 | 46.1 | 13.6 | 29.5 |
| ZR36K3PFJ522 | 8850 | 3 | 49,5 | 16.4 | 29.5 |
| ZR40K3PFJ522 | 9620 | 3.33 | 54.19 | 17.1 | 32 |
| ZR42K3PFJ522 | 10140 | 3.5 | 56,8 | 17.1 | 30 |
| ZR47K3PFJ522 | 11500 | 3.9 | 64.1 | 19.3 | 32.6 |
| ZR68KCPFJ522 | 16800 | 5,75 | 93 | 28.2 | 43,5 |
| ZR28K3TFD522 | 6970 | 2.33 | 39.2 | 5 | 26 |
| ZR28K3ETFD522 | 6970 | 2.33 | 39.2 | 5 | 26 |
| ZR36K3TFD522 | 8850 | 3 | 49,5 | 5.7 | 29.5 |
| ZR40K3TFD522 | 9260 | 3.33 | 51.2 | 6.4 | 32 |
| ZR47KCTFD522 | 11400 | 3.9 | 63.2 | 7.2 | 32.6 |
| ZR47KCETFD522 | 11400 | 3.9 | 63.2 | 7.2 | 32.6 |
| ZR48KCTFD522 | 11500 | 4.1 | 67.2 | 7.5 | 38 |
| ZR48KCETFD522 | 11500 | 4.1 | 67.2 | 7.5 | 38 |
| ZR54KCTFD522 | 13000 | 4.5 | 73,2 | 8.2 | 35,5 |
| ZR57KCTFD522 | 13660 | 4,75 | 76,9 | 8.2 | 36 |
| ZR57KCETFD522 | 13660 | 4,75 | 76 | 8.2 | 36 |
| ZR61KCTFD522 | 14700 | 5 | 82,4 | 10 | 35.9 |
| ZR61KCETFD522 | 14700 | 5 | 82,4 | 10 | 35.9 |
| ZR68KCTFD522 | 16500 | 5,75 | 93 | 10 | 38.2 |
| ZR72KCTFD522 | 17800 | 6 | 98 | 10 | 38.2 |
| ZR72KCETFD522 | 17800 | 6 | 98 | 10 | 38.2 |
| ZR81KCTFD522 | 19800 | 6,75 | 110.6 | 12 | 40 |
| ZR81KCETFD522 | 19800 | 6,75 | 110.6 | 12 | 40 |
| ZR94KCTFD522 | 23000 | 8 | 127.2 | 16.2 | 59 |
| ZR94KCTFD523 | 23200 | 8 | 127.2 | 16.2 | 58.2 |
| ZR94KCETFD523 | 23200 | 8 | 127.2 | 16.2 | 58.2 |
| ZR108KCTFD522 | 26670 | 9 | 147,5 | 17.3 | 64 |
| ZR108KCETFD523 | 26670 | 9 | 147,5 | 17.3 | 64 |
| ZR108KCTFD523 | 26900 | 9 | 144,5 | 17.3 | 62,7 |
| ZR125KCTFD522 | 30660 | 10 | 171,4 | 19.2 | 64 |
| ZR125KCETFD523 | 31000 | 10 | 165,6 | 19.2 | 62,7 |
| ZR125KCTFD523 | 31000 | 10 | 165,6 | 19.2 | 62,7 |
| ZR144KCTFD522 | 34700 | 12 | 191,7 | 19.6 | 62,7 |
| ZR144KCETFD523 | 34700 | 12 | 191,7 | 19.6 | 62,7 |
| ZR144KCTFD523 | 34700 | 12 | 191,7 | 19.6 | 62,7 |
| ZR16M3TWD551 | 37700 | 13 | 204.3 | 25 | 103.1 |
| ZR16M3ETWD551 | 37700 | 13 | 204.3 | 17.3 | 103 |
| ZR19M3TWD551 | 45900 | 15 | 241,9 | 23.8 | 112.1 |
| ZR19M3ETWD551 | 45900 | 15 | 241,9 | 23.8 | 119 |
